Electromagnetic Sieve Shaker Manufacturer in Mumbai - Technosearch Instruments
Technosearch Instruments, based in Mumbai, India, is a leading manufacturer and supplier of Electromagnetic Sieve Shakers designed for accurate particle size analysis in laboratories, research institutions, and industries. Our TSI Sieve Shakers (Models TSSTD, TSSMT, TSCFT) are engineered with advanced microprocessor-based control systems to deliver consistent, reproducible, and noise-free results for both dry and wet sieving applications.
Electromagnetic Sieve Shaker - Overview :
The Technosearch Electromagnetic Sieve Shaker is suitable for all types of sieving tasks in labs and onsite testing. It combines 3D circular and vertical motion to ensure efficient separation while preventing blinding of sieve apertures.
» Circular sieving motion ensures even material distribution.
» Rapid vertical movement prevents clogging of sieve mesh.
» Microprocessor-controlled design for precision, repeatability, and ease of use.
» Low noise operation (<61 dB) with minimal maintenance requirements.
» Compatible with 100 mm to 200/203 mm sieves and supports wet sieving attachments (optional).
Key Advantages of Technosearch Sieve Shakers :
» Easy to lock/unlock with quick assembly.
» Suitable for 100 mm, 150 mm, 200/203 mm sieves.
» Wet sieve attachment support (optional).
» Adjustable power and time settings for reproducible results.
» Electromagnetic vibration principle - low maintenance and smooth operation.
» Noise level <61 dB without sieves.
Standard Specifications (All Models) :
» Display : 16×2 / 20×4 LCD Digital Display
» Parameters : Power, Time, Amplitude
» Power Range : 1 to 20 (programmable)
» Amplitude Range : 0.5 to 3.0 mm*
» Timer Range : 1 to 99 minutes (accuracy 0.1%)
» Power Requirement : 230 V AC, 50/60 Hz (5A) or 110 V AC, 50/60 Hz (10A)
» Dimensions : 380 × 310 × 740 mm
» Weight : ~48 kg (without sieves)
» Documentation : User Manual, IQ/OQ Validation Documents
» Standard Accessories : Supporting rods (2), easy lock knobs (2), receiver pan, top lid, silicone pad, mains cord, operating manual
» Optional Accessories : Wet sieve attachment, 100 mm lid/receiver
Comparison of Electromagnetic Sieve Shaker Models :
Specification / Feature |
TSSTD |
TSSMT |
TSCFT |
Vibration Amplitude |
0.5 – 2.0 mm |
0.5 – 2.5 mm |
0.1 – 3.0 mm |
Motion Type |
3D Shifting Motion |
3D Shifting Motion |
3D Shifting Motion |
Modes of Operation |
2 Modes – Continuous & Intermittent |
3 Modes – Continuous, Intermittent, Combined |
3 Modes – Continuous, Intermittent, Combined |
Protocols |
Not Available |
Up to 10 protocols (load/store) |
Up to 10 protocols (load/store) |
Display |
20×4 LCD, shows model & serial no. |
20×4 LCD, shows model & serial no. |
20×4 Blue LCD, digital amplitude processing |
Capacity (200 mm sieves) |
Up to 8 sieves × 50 mm height |
Up to 8 sieves × 50 mm height |
Up to 9 sieves × 50 mm height |
Capacity (100 mm sieves) |
Up to 16 sieves × 25 mm height |
Up to 16 sieves × 25 mm height |
Up to 16 sieves × 25 mm height |
Suitable Sieves |
10 μm to 8 mm |
10 μm to 8 mm |
10 μm to 8 mm |
Shake Time |
1 to 99 minutes (programmable) |
1 to 99 minutes (programmable) |
1 to 99 minutes (programmable) |
Power Requirement |
220/230 V AC, 50 Hz, 600 VA |
220/230 V AC, 50 Hz, 600 VA |
220/230 V AC, 50 Hz, 600 VA |
Weight (Approx.) |
48 kg |
48 kg |
48 kg |
Applications of Electromagnetic Sieve Shaker :
» Pharmaceutical Industry - particle size distribution in powders and granules.
» Food & Beverage - sieving flour, sugar, spices, and powders.
» Chemical Industry - quality control of raw materials and intermediates.
» Construction & Cement - sieve analysis of sand, cement, aggregates.
» Research & Academic Labs - particle size analysis and material testing.
